Marine Hoses Quality Control Process
1、Coupling
Welding,NDT,Galvanization
Flange Area
- Flange Area
Ⅰ. Flange
Flange Material: ASTM A-105/ASTM A-105C
Equivalent Material Standards: BS 1503:221-430, DIN 17200/SEW 550: C22.8, JIS G 3201 SF 440
Flange Rating: ASME B16.5 Class 150 or Class300 (as per client’s requirement)
Welding Procedures and Welder: ASME IX
Flange MTC
① Material Chemical Composition
② Mechamical Performance: Tensile Test, Impact Test, Hardness Test, Bending Test
③ Visual Inspection
Main Procedures for the Flange Production and Examination: Flange Factory
① Heat Treatment
② Welding
③ Radiographic Examination
④ Magnetic Particle Examination
Flange Re-process Procedure:
① Hot-dip galvanized, min. average coating weight 610g/m2 (equivalent to 85µm thickness)
② Pickled in acid to get rid of the iron scum
③ Grit blasting to get more contact surface
④ Painting Adhesive
⑤ Flange Installed on Mandrel
Marking:
① the year of manufacture and hose serial number will be applied on the rim of each flange
② one flange rim marked with letter “A” and the other with “B”
